Authoritative certified mold-resistant materials: through the military standard mold resistance test (GJB150.10), an alternative to CNAS.
1. UL certified V0 grade polyether TPU:
UL94-V0 (1.5mm) flame retardant grade, fully support the conventional structural cable through the theIEC60332-1-2 single vertical burning test;
2. Extremely small high and low-temperature shrinkage rate, shrinkage rate ≤1% in high and low-temperature cycle test;
3. High security and reliability, support fiber optic cable through various environmental tests and life tests:
4. High wear resistance:
Polar material, high cohesive energy, and wear resistance are much better than conventional low-smoke halogen-free polyolefin materials (LSZH);
5. Excellent processing performance:
Fully meet the requirements of cable jacket filling, semi-filling, empty pipe extrusion, and high-speed ultra_x005f thin wall (≤0.1mm, 80-200m/min)extrusion requirements. high yield rate, and low degradation performance such as runny, broken skin, granules, coarse hemp, mold marks, and stereotypes.
6. Advanced appearance:
The even and delicate frosted surface (matte surface) not only makes the cable wear-resistant, reliable high-quality texture but also suitable for the extinction requirements of military optical cables." most used in Military&Aerospace cables.
Technical Data Sheet | Model | ||||
Material Properties | Test Standard | Test Condition | Unit | 1185D-ENB-1414S | |
General Characteristics | Material Category | - | - | - | |
Appearance(Light/Semi-matte/Frosted) | - | - | - | ||
Extrusion/Injection | - | - | - | ||
Physical Characteristics | Hardness | ISO 48 | 15S | Shore A | 85 |
Proportion | ISO 1183 | - | g/cm³ | 1.185 | |
Melt Index | ISO 1133-1:2011 | 190℃/2.16kg | g/10min | 9.6 | |
Brittle Temperature | ISO 812 | - | ℃ | ||
Mechanical Properties | Elongation | ISO37:2017 | 200mm/min | % | 492 |
Tensile Strength | ISO37:2017 | 200mm/min | Mpa | 26.1 | |
Tearing Strength | ISO34-1:2015 | 500mm/min | KN/m | ||
Hot Air Aging | Elongation Retention Rate | ISO37:2017 | - | % | |
Tensile Strength Retention Rate | ISO37:2017 | - | % | ||
Electrical Performance | Volume Resistivity | ASTM D257 | - | Ohm-cm | |
Permittivity | ASTM D150 | - | - | ||
Combustion Performance | Vertical Burning Test | UL 94 | 3.0/6.0mm | - | |
Oxygen Index | ASTM D2863 | - | % | ||
Feature |
